Frame

Columns (optional with integrated cable management) of square tubes 100 x 100 x 2 mm, with a rectangular steel baseplate 700 x 120 mm chrome-plated or black powder-coated, powder-coated to BRUNE^® collection and weighted plate made of steel, powder-coated. Comes with height-adjustable floor slides. Upper frame with profiled screw plate 400/400 x 12 mm for mounting the table top using special screws. At HPL, screw plates are in a standard powder-coated white; and with veneer with a standard powder-coated black.

Frame surfaces

Column and base plate have a chrome finish as standard, in black or optionally powder-coated according to BRUNE^® collection.

Table Tops

Plate C: 40 mm thick, high-quality multi-layer plywood plate E1, top surface optionally covered with HPL plastic or wood veneer according to BRUNE^® collection. Lower surface white HPL or beech veneer. Straight edge, 2 mm thick, in material to match table top (plastic for plastic, veneer for veneer).

Veneer finish

Real wood veneer from BRUNE^® collection comes as a standard varnished with a low solvent content water-based lacquer, optionally stained to BRUNE^® collection.

HPL surfaces

Resopal^®-HPL from BRUNE^® collection.

Gliders

Plastic gliders with height adjustment.

Dimensions

Table height:
top C 76.0 cm

4550 Weights:

• 180x100 cm: 145 kg

• 200x100 cm: 150 kg

• 240x100 cm: 161 kg

• 300x100 cm: 178 kg

• 180x110 cm: 150 kg

• 200x110 cm: 156 kg

• 240x110 cm: 168 kg

• 300x110 cm: 187 kg

• 180x120 cm: 155 kg

• 200x120 cm: 161 kg

• 240x120 cm: 175 kg

• 300x120 cm: 195 kg

4551 Extension weights:

• 180x100 cm: 101 kg

• 200x100 cm: 106 kg

• 180x110 cm: 106 kg

• 200x110 cm: 117 kg

• 180x120 cm: 111 kg

• 200x120 cm: 118 kg

4552 Quarter-circle weights:

• 100x100 cm: 72 kg

• 110x110 cm: 77 kg

• 120x120 cm: 82 kg
