GRAND TABLE
GRAND TABLE – the timeless conference table. GRAND TABLE offers a large variety of design options suitable for meeting and conference rooms. The classic conference table shapes i.e. rectangular and barrel shape are available in different sizes and can be combined as desired. Cable management systems and net boxes are equally available.
Downloads
- 4520_210x100_Tonnenform.dwg
(430 KB) - 4520_240x110_Rechteck.dwg
(362 KB) - 4520_240x110_Tonnenform.dwg
(432 KB) - 4520_300x120_Rechteck.dwg
(362 KB) - 4520_300x120_Tonnenform.dwg
(365 KB) - 4520_480x130_Rechteck.dwg
(298 KB) - 4520_480x130_Tonnenform.dwg
(338 KB) - DWG_4520_210x100_Rechteckform.dwg
(361 KB) - 4520_GRAND_TABLE_Produktinformation_EN_Mail.pdf
(721 KB)

Frame
4-legged base made of rectangular steel tube, steel legs made of rectangular tube 70 x 30 x 2 mm, screwed to the frame. Frame made of rectangular tube 50 x 15 x 2 mm.
6-legged base made of rectangular steel tube, steel legs made of rectangular tube 70 x 30 x 2 mm, screwed to the frame. Frame made of rectangular tube 50 x 15 x 2 mm.
Frame surfaces
4-legged base, steel legs standard chromium-plated or powder-coated black, optionally powder-coated according
to the BRUNE® collection. Frame standard powder-coated black, optionally powder-coated according to the BRUNE® collection.
6-legged base, steel legs standard chromium-plated or powder-coated black, optionally powder-coated according to the BRUNE® collection. Frame standard powder-coated black, optionally powder-coated according to the BRUNE® collection.
Table tops
Table top C: 30 mm thick, multi-layer particle board, E1, coated in high pressure laminate (HPL) or veneer according to BRUNE® collection. Plate bottom side HPL white or beech veneer. ABS edging in connection with laminated top or veneer edging in combination with veneered table top.
Table top R: 30 mm thick, MDF, surface coated in high-pressure laminate (HPL) or veneer according to BRUNE® collection. Underside: HPL white or beech veneer. Edges MDF, straight edges, 10 mm thick, beveled over 45 mm. Edge MDF stained and lacquered. For veneer, straight edge veneer, bevelled edge MDF, stained and lacquered.
Veneer fisnish
Real wood veneer from the BRUNE® collection comes as a standard varnished with a low solvent content water-based lacquer, optionally stained to the BRUNE® collection.
HPL surfaces
Resopal®-HPL from the BRUNE® collection.
Gliders
Standard plastic gliders.
Dimensions and weight
| Height: | 75 cm | |||
Width min. Length min. | 80 cm 140 cm | |||
| 210 x 100 cm 240 x 110 cm 300 x 120 cm | 63 kg 75 kg 96 kg | |||
| 210 x 100 cm 240 x 110 cm 300 x 120 cm 480 x 130 cm | 60 kg 71 kg 90 kg 164 kg |

Eduard Euwens
Eduard Euwens (born 1970) completed an apprenticeship as cabinet maker before he started studying design in Münster. In 2000 he finished his studies as diploma designer and since then acquired experience as designer in several offices. Since 2004, he dedicated himself to the development of goods for daily use with his own studio. His works for BRUNE have already been acknowledged by the design council.
Eduard Euwens is living and working in Münster.
